Dahua Technology WizMind IPC-PFW5849-A180-E2-ASTE. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Wall/Pole, Product colour: White, Form factor: Bullet. Angle of rotation: 360°, Lens viewing angle, horizontal: 180°, Lens viewing angle, vertical: 48°. Sensor type: CMOS, Optical sensor size: 25.4 / 1.8 mm (1 / 1.8"). Detect distance: 70.3 m, Observe distance: 28.1 m, Recognize distance: 14.1 m
Performance
Performance
- Type: IP security camera
- Placement supported: Indoor & outdoor
- Connectivity technology: Wired
- Wide Dynamic Range (WDR): Yes
- Day/night mode: Yes
- Alarm input/output: Yes
- Built-in light: Yes
- Dynamic range: 140 dB
- Form factor: Bullet
- Mounting type: Wall/Pole
- Product colour: White
- Housing material: Metal, Plastic
- International Protection (IP) code: IP67
- Minimum illumination: 0 lx
- Angle of rotation: 360°
- Lens viewing angle, horizontal: 180°
- Lens viewing angle, vertical: 48°
- Tilt angle range: 0 - 90°
- Pan range: 0 - 360°
- White balance: Auto, Manual, Natural, Outdoor, Street lamp
- Camera shutter type: Electronic
- Camera shutter speed: 1/3 - 1/100000 s
- Adjustment shutter speed: Auto/Manual
- Number of Privacy masking areas: 4
- Number of sensors: 2
- Optical sensor size: 25.4 / 1.8 mm (1 / 1.8")
- Progressive scan: Yes
- Sensor type: CMOS
- Number of lenses: 2
- Detect distance: 70.3 m
- Observe distance: 28.1 m
- Recognize distance: 14.1 m
- Maximum aperture number: 1
- Identify distance: 7 m
- Fixed focal length: 3.6 mm
- Closest focusing distance: 3.6 m
- Night vision: Yes
- Night vision distance: 40 m
- Maximum resolution: 4096 x 1800 pixels
- Total megapixels: 4 MP
- Video formats supported: H.264, H.264+, H.265, H.265+, M-JPEG
- Video compression formats: H.264, H.264+, H.264H, H.265, H.265+
- Supported graphics resolutions: 1920 x 832, 2880 x 1264, 3840 x 1080, 3840 x 1680, 4096 x 1800
- Video recording: Yes
- Frame rate: 25 fps
- Video streaming: Yes
- Noise reduction: Yes
- Noise reduction technology: 3D noise reduction
- Gain control type: Auto
- Privacy masking: Yes
- Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
- Bit rate: H.264: 9 kbps–8192 kbps H.265: 9 kbps–8192 kbps
- Back Light Compensation (BLC): Yes
- Highlight Compensation (HLC): Yes
- Region of Interest (ROI) encoding: Yes
- Audio input channels: 1.0 channels
- Audio output channels: 1.0 channels
- Audio formats supported: G.711, G.723, G.726, PCM
- Signal-to-Noise Ratio (SNR): 56 dB
- Built-in microphone: Yes
- Ethernet LAN: Yes
- Ethernet interface type: Fast Ethernet
- Supported network protocols: IPv4; IPv6; HTTP;TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; Bonjour
- Wi-Fi: No
- Bluetooth: No
- Number of users: 20 user(s)
- Quality of Service (QoS) support: Yes
- Built-in HDD: No
- Compatible memory cards: MicroSD (TransFlash)
- Maximum memory card size: 512 GB
- Internal memory: 1000 MB
- ROM capacity: 128 MB
- Alarm input channels: 1
- Alarm output channels: 1
- Video motion detection: Yes
- Privacy protection: Yes
- Web browser: Yes
- Management software: Smart PSS; DSS; DMSS
- Power source type: DC, PoE
- Power consumption (typical): 4.8 W
- Power consumption (max): 10.5 W
- Power consumption (Power over Ethernet (PoE)): 5.5 W
- DC output voltage: 12
- Operating temperature (T-T): -40 - 60 °C
- Storage temperature (T-T): -40 - 60 °C
- Operating relative humidity (H-H): 0 - 95%
- Mobile operating systems supported: Android, iOS
- Width: 128.2 mm
- Depth: 301.2 mm
- Height: 120.1 mm
- Weight: 1.42 kg
- Package weight: 1.57 kg
- Number of cameras: 1
- Warranty period: 5 year(s)
