Dahua Technology Lite DH-HAC-HFW1400S. Type: CCTV security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling/Wall/Pole, Product colour: White, Form factor: Bullet. Minimum illumination: 0.03 lx, Angle of rotation: 360°, Lens viewing angle, horizontal: 97°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.7 mm (1 / 2.7"). Detect distance: 56 m, Observe distance: 22 m, Recognize distance: 11 m
Performance
- Type: CCTV security camera
- Placement supported: Indoor & outdoor
- Connectivity technology: Wired
- Wide Dynamic Range (WDR): Yes
- Day/night mode: Yes
- Infrared (IR) cut-off filter: Yes
- Remote viewing: Yes
- Number of languages: 11
- Languages support: Simplified Chinese, German, English, Estonian, French, Italian, Japanese, Korean, Polish, Portuguese, Russian
- Certification: CE (EN55032, EN55024, EN50130-4) FCC (CFR 47 FCC Part 15 subpart B, ANSI C63.4-2014) UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
Design
- Form factor: Bullet
- Mounting type: Ceiling/Wall/Pole
- Product colour: White
- Housing material: Aluminium
- International Protection (IP) code: IP67
Camera
- Camera pan control: Yes
- Camera tilt control: Yes
- Minimum illumination: 0.03 lx
- Angle of rotation: 360°
- Lens viewing angle, horizontal: 97°
- Lens viewing angle, vertical: 52°
- Tilt angle range: 0 - 90°
- Pan range: 0 - 360°
- White balance: Auto, Manual
- Camera shutter speed: 1/25 - 1/100000 s
Image sensor
- Number of sensors: 1
- Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")
- Progressive scan: Yes
- Sensor type: CMOS
Lens system
- Number of lenses: 1
- Detect distance: 56 m
- Observe distance: 22 m
- Recognize distance: 11 m
- Fixed focus: Yes
- Maximum aperture number: 2
- Identify distance: 6 m
- Fixed focal length: 2.8 mm
- Closest focusing distance: 0.8 m
Night vision
- Night vision: Yes
- Night vision distance: 30 m
- LED type: IR
- Number of illumination LEDs: 18
Video
- Maximum resolution: 2560 x 1440 pixels
- Total megapixels: 4 MP
- Supported graphics resolutions: 1920 x 1080 (HD 1080), 2560 x 1440
- Supported video modes: 1080p
- Frame rate: 25 fps
- Analog signal format system: PAL
- Noise reduction: Yes
- Gain control type: Auto
- Back Light Compensation (BLC): Yes
- Highlight Compensation (HLC): Yes
- Digital Wide Dynamic Range (DWDR): Yes
- Smart IR: Yes
Network
- Ethernet LAN: No
- Wi-Fi: No
- Bluetooth: No
Storage
- Built-in HDD: No
Ports & interfaces
- Composite video out: 1
Power
- Power source type: DC
- Power consumption (max): 4.9 W
- DC output voltage: 12
Operational conditions
- Operating temperature (T-T): -40 - 60 °C
- Storage temperature (T-T): -40 - 60 °C
- Operating relative humidity (H-H): 0 - 90%
- Storage relative humidity (H-H): 0 - 90%
Weight & dimensions
- Width: 164.7 mm
- Depth: 70 mm
- Height: 71.6 mm
- Weight: 380 g
Packaging data
- Package weight: 470 g
Packaging content
- Number of cameras: 1
