Dahua Technology Explosion-Proof EPC230U. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Wall, Product colour: Stainless steel, Form factor: Bullet. Minimum illumination: 0.0005 lx, Lens viewing angle, horizontal: 2.4 - 67.8°, White balance: ATW, Auto, Indoor, Manual, Outdoor. Sensor type: CMOS, Optical sensor size: 25.4 / 2.8 mm (1 / 2.8"), Number of effective pixels (H x V): 1920 x 1080 pixels. Optical zoom: 30x, Digital zoom: 16x, Detect distance: 1862 m
Performance
Performance
- Type: IP security camera
- Placement supported: Indoor & outdoor
- Connectivity technology: Wired
- PTZ control: Yes
- Auto-tracking: No
- Wide Dynamic Range (WDR): Yes
- Day/night mode: Yes
- Alarm input/output: Yes
- Dynamic range: 120 dB
- Certification: CE: EN55032/EN55024/EN50130-4 FCC: Part15 subpartB,ANSI C63.4- 2014 ATEX: EN 60079-0/EN 60079-1/EN 60079-31 IECEx : IEC 60079-0/IEC 60079-1/IEC 60079-31
- Form factor: Bullet
- Mounting type: Wall
- Product colour: Stainless steel
- Housing material: Stainless steel
- Protection features: Water resistant, Waterproof
- International Protection (IP) code: IP68
- Minimum illumination: 0.0005 lx
- Lens viewing angle, horizontal: 2.4 - 67.8°
- White balance: ATW, Auto, Indoor, Manual, Outdoor
- Camera shutter speed: 1/1 - 1/30000 s
- Adjustment shutter speed: Auto
- Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
- Progressive scan: Yes
- Sensor type: CMOS
- Number of effective pixels (H x V): 1920 x 1080 pixels
- Zoom capability: Yes
- Optical zoom: 30x
- Digital zoom: 16x
- Number of lenses: 1
- Detect distance: 1862 m
- Observe distance: 744 m
- Recognize distance: 372 m
- Focal length range: 4.5 - 135 mm
- Auto focus: Yes
- Focus: Motorized/Manual
- Maximum aperture number: 4.4
- Identify distance: 186 m
- Minimum aperture number: 1.6
- Closest focusing distance: 1 m
- Night vision: Yes
- Night vision distance: 100 m
- LED type: IR
- Number of illumination LEDs: 6
- Maximum resolution: 1920 x 1080 pixels
- Total megapixels: 2 MP
- Video compression formats: H.264, H.264+, H.265, H.265+
- Supported graphics resolutions: 352 x 240, 352 x 288, 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080)
- Supported video modes: 720p, 1080p
- Frame rate: 60 fps
- Video streaming: Yes
- Noise reduction: Yes
- Noise reduction technology: Ultra 2D noise reduction, Ultra 3D noise reduction
- Gain control type: Auto/Manual
- Privacy masking: Yes
- Image stabilizer: Yes
- Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
- Bit rate: 448 - 8192
- Back Light Compensation (BLC): Yes
- Highlight Compensation (HLC): Yes
- Region of Interest (ROI) encoding: Yes
- Audio input channels: 1.0 channels
- Audio output channels: 1.0 channels
- Signal-to-Noise Ratio (SNR): 55 dB
- Ethernet LAN: Yes
- Supported network protocols: IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP,DHCP, DNS,PPPOE,DDNS,FTP, IP Filter,QoS,Bonjour,802.1x
- Number of users: 20 user(s)
- Quality of Service (QoS) support: Yes
- Streaming method: Multicast, Unicast
- Card reader integrated: Yes
- Compatible memory cards: MicroSD (TransFlash)
- Maximum memory card size: 256 GB
- Flash memory: 512 MB
- ROM capacity: 128 MB
- Ethernet LAN (RJ-45) ports: 1
- RS-485 ports: 1
- BNC output ports: 1
- Alarm input channels: 2
- Alarm output channels: 1
- Security algorithms: HTTPS, SSL/TLS
- HTTPS encryption: Yes
- Intelligent Video Surveillance (IVS) system features: Abandoned object, Face detection, Heat map, Intrusion, Missing object, Tripwire
- Motion sensor: Yes
- Web-based management: Yes
- Web browser: Yes
- Management software: Smart PSS, DSS, DMSS
- Power source type: AC, PoE
- AC input voltage: 100 - 240 V
- Power consumption (typical): 10 W
- Power consumption (max): 25 W
- Operating temperature (T-T): -40 - 60 °C
- Operating relative humidity (H-H): 0 - 95%
- Mobile operating systems supported: Android, iOS
- Width: 149.5 mm
- Height: 143 mm
- Diameter: 39.6 cm
- Weight: 8.7 kg
- Package weight: 10.4 kg
- Number of cameras: 1
