Dimensiones: 441mm (19") x 272mm x 222mm (5 U)
Peso: 13 Kg (incluyendo todas las tarjetas)
GPON Compliant
ITU-T 984.1
ITU-T 984.2
ITU-T 984.3
ITU-T 984.4
ITU-T 984.7
Dynamic bandwidth allocation for upstream bandwidth dynamic adjustment
Forward error correction
GPON encapsulation method fragmentation
GPON Type-B protection
Rogue ONT detection
1:128 ONT support per PON port
Topology Protocols
ERPS
Ring/Tree/Star topology
STP/RSTP/MSTP
Link aggregation
Switch Function
IEEE 802.1q VLAN
IEEE 802.1ad VLAN stacking
VLAN translation 1:1
VLAN translation N:1
Jumbo frame
Mirroring by port
Mirroring by VLAN
Port isolation
Multicast
IGMPv1, v2, v3 snooping
Fast leave
Multicast VLAN
Security
DHCP Relay agent
PPPoE IA
Static MAC
Drop packet by ACL
MAC limit per port
MAC filtering source/destination MAC
Storming control
Anti MAC spoofing
Prevent ARP spoofing
DDoS
QoS
IEEE 802.1P
Ingress port rate limit
Egress port rate limit
Scheduling algorithm SP, SP+WFQ, WFQ
Limit packet rate by ACL
OAM&.P
SNMP
In band management/Out-of-band management
CLI via console port/Telent/SSH
Web GUI
NetAtlas EMS
