Dahua Technology Lite DH-IPC-HDW3241TM-AS. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: White, Form factor: Dome. Minimum illumination: 0.002 lx, Angle of rotation: 360°, Lens viewing angle, horizontal: 106°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.8 mm (1 / 2.8"). Detect distance: 38.6 m, Observe distance: 15.4 m, Recognize distance: 7.7 m
Performance
Performance
- Type: IP security camera
- Placement supported: Indoor & outdoor
- Connectivity technology: Wired
- Wide Dynamic Range (WDR): Yes
- Day/night mode: Yes
- Infrared (IR) cut-off filter: Yes
- Remote viewing: Yes
- Certification: CE-LVD: EN60950-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07
- Form factor: Dome
- Mounting type: Ceiling/wall
- Product colour: White
- Housing material: Metal, Plastic
- Protection features: Dust resistant, Water resistant
- International Protection (IP) code: IP67
- Camera pan control: Yes
- Camera tilt control: Yes
- Minimum illumination: 0.002 lx
- Angle of rotation: 360°
- Lens viewing angle, horizontal: 106°
- Lens viewing angle, vertical: 57°
- Lens viewing angle, diagonal: 126°
- Tilt angle range: 0 - 78°
- Pan range: 0 - 360°
- White balance: Auto, Manual, Natural, Outdoor
- Camera shutter speed: 1/3 - 1/100000 s
- Number of sensors: 1
- Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
- Progressive scan: Yes
- Sensor type: CMOS
- Number of lenses: 1
- Detect distance: 38.6 m
- Observe distance: 15.4 m
- Recognize distance: 7.7 m
- Identify distance: 3.9 m
- Fixed focal length: 2.8 mm
- Closest focusing distance: 0.6 m
- Night vision: Yes
- Night vision distance: 50 m
- LED type: IR
- Number of illumination LEDs: 2
- Maximum resolution: 1920 x 1080 pixels
- Total megapixels: 2 MP
- Video compression formats: H.264, H.265, M-JPEG
- Supported graphics resolutions: 352 x 240, 352 x 288, 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080)
- Supported video modes: 720p, 1080p
- Analog signal format system: PAL
- Video streaming: Yes
- Noise reduction: Yes
- Noise reduction technology: 3D noise reduction
- Gain control type: Auto
- Privacy masking: Yes
- Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
- Bit rate: 3 Kbps - 8192 Kbps
- Back Light Compensation (BLC): Yes
- Highlight Compensation (HLC): Yes
- Region of Interest (ROI) encoding: Yes
- Smart IR: Yes
- Audio codecs: G.711a, G.711Mu, G726, AAC
- Built-in microphone: Yes
- Ethernet LAN: Yes
- Ethernet interface type: Fast Ethernet
- Networking standards: IEEE 802.3af
- Supported network protocols: HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPoE; IPv4/v6; SNMP; QoS; UPnP; NTP
- Wi-Fi: No
- Bluetooth: No
- Number of users: 20 user(s)
- Quality of Service (QoS) support: Yes
- Built-in HDD: No
- Card reader integrated: Yes
- Compatible memory cards: MicroSD (TransFlash)
- Maximum memory card size: 256 GB
- Internal memory: 256 MB
- ROM capacity: 128 MB
- Ethernet LAN (RJ-45) ports: 1
- Video motion detection: Yes
- Intelligent Video Surveillance (IVS) system features: Intrusion, Tripwire
- Mirror: Yes
- Web-based management: Yes
- Web browser: Yes
- Power source type: DC, PoE
- Power consumption (max): 7.7 W
- DC output voltage: 12
- Operating temperature (T-T): -40 - 60 °C
- Storage temperature (T-T): -40 - 60 °C
- Operating relative humidity (H-H): 0 - 95%
- Mobile operating systems supported: Android, iOS
- Height: 99.1 mm
- Diameter: 12.2 cm
- Weight: 480 g
- Package weight: 660 g
- Number of cameras: 1
