Nuevo

Domo IP H265 4M WDR140dB Deeplight IR40m 2.7-12VFM IK10 IP67 PoE+ SD AUDIO E/S AI

Marca: DAHUA

Referencia DHI-IPC-HDBW7442E1-Z-X

Dahua Technology WizMind IPC-HDBW5449RP-ASE-LED-0280B, IP security camera, Indoor & outdoor, Wired, 140 dB, CE-LVD: EN62368-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part..., Ceiling

Descripción

Dahua Technology WizMind IPC-HDBW5449RP-ASE-LED-0280B. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling, Product colour: White, Form factor: Bullet. Minimum illumination: 0.0005 lx, Angle of rotation: 355°, Lens viewing angle, horizontal: 115 - 48°. Sensor type: CMOS, Optical sensor size: 25.4 / 1.8 mm (1 / 1.8"), Number of effective pixels (H x V): 2688 x 1520 pixels. Focal length range: 2.7 - 12 mm, Focus: Motorized, Detect distance (wide): 60.4 m

Performance

Type: IP security camera
Placement supported: Indoor & outdoor
Connectivity technology: Wired
Day/night mode: Yes
Dynamic range: 140 dB
Certification: CE-LVD: EN62368-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-

Design

Form factor: Bullet
Mounting type: Ceiling
Product colour: White
Housing material: Metal
International Protection (IP) code: IP67
IK code: IK10

Camera

Minimum illumination: 0.0005 lx
Angle of rotation: 355°
Lens viewing angle, horizontal: 115 - 48°
Lens viewing angle, vertical: 59 - 27°
Lens viewing angle, diagonal: 142 - 55°
Tilt angle range: 0 - 80°
Pan range: 0 - 355°
White balance: Auto, Manual, Natural, Outdoor, Street lamp
Camera shutter speed: 1/3 – 1/100000

Image sensor

Optical sensor size: 25.4 / 1.8 mm (1 / 1.8")
Progressive scan: Yes
Sensor type: CMOS
Number of effective pixels (H x V): 2688 x 1520 pixels

Lens system

Number of lenses: 1
Focal length range: 2.7 - 12 mm
Focus: Motorized
Maximum aperture number: 2.8
Detect distance (wide): 60.4 m
Detect distance (tele): 128.6 m
Observe distance (wide): 24.1 m
Observe distance (tele): 51.4 m
Recognize distance (wide): 12 m
Recognize distance (tele): 27.5 m
Identify distance (wide): 6 m
Identify distance (tele): 12.8 m
Closest focusing distance: 1.75 m

Night vision

Night vision: Yes
Night vision distance: 40 m
LED type: IR
Number of illumination LEDs: 3

Video

Maximum resolution: 2688 x 1520 pixels
Total megapixels: 4 MP
Video formats supported: H.264+, H.265+
Video compression formats: H.264, H.264B, H.264H, H.265
Supported graphics resolutions: 352 x 240, 352 x 288, 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080), 2304 x 1296, 2560 x 1440, 2688 x 1520
Supported video modes: 720p, 1080p
Frame rate: 60 fps
Noise reduction: Yes
Noise reduction technology: 3D noise reduction
Gain control type: Auto/Manual
Privacy masking: Yes
Bit rate control: Constant Bit Rate (CBR), Variable Bit Rate (VBR)
Bit rate: H.264: 3 kbps–20480 kbps H.265: 3 kbps–20480 kbps
Back Light Compensation (BLC): Yes
Highlight Compensation (HLC): Yes
Region of Interest (ROI) encoding: Yes

Audio

Audio input channels: 1.0 channels
Audio output channels: 1.0 channels
Audio formats supported: G.711, G.723, PCM
Signal-to-Noise Ratio (SNR): 56 dB
Built-in microphone: Yes

Network

Ethernet LAN: Yes
Supported network protocols: IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; 802.1x; SNMP
Number of users: 20 user(s)

Storage

Compatible memory cards: SD
Maximum memory card size: 256 GB
Internal memory: 512 MB
ROM capacity: 128 MB

Ports & interfaces

Ethernet LAN (RJ-45) ports: 1

Security

Alarm input channels: 1
Alarm output channels: 1
Video motion detection: Yes
Intelligent Video Surveillance (IVS) system features: Abandoned object, Heat map, Missing object
Mirror: Yes

Management features
